Home Products Screw Air Compressor

Screw Air Compressor

We are the authorized dealer of Drytech Engineers.

High-Efficiency Intake Filter System

Big surface air filter element can effectively eliminate dust particles from intake cooling air and simultaneously maintains a low noise level.

Reliable Automatic Control Box

Electronic components of the IP54 automatic control box such as relays, contactors and overload relays are from the named brand Siemens to deliver a safe and trustworthy compressor control solution.

Multi-Stage Air/Oil Separation System

Multi-Stage Air/Oil Separation System

The latest European Patented multi-stage air/oil separation system promises low residual oil content of less than 1 – 3 ppm. These devices by Saimona Compressor LTD transcends any international standard of oil-injected rotary screw air compressors and is specifically appropriate for customers with clean air for applications.

Modern Concept Suction Control System

The control unit of the suction control valve can automatically adjust from 60- 100% according to the system air demand in order to successfully reduce operating costs.

Intelligent PLC Control Panel

This convenient-to-use electric control panel continuously monitors and displays overall system performance status with proactive service indications, alarms for malfunctions and safety shutdowns. Advanced sequence control for multi-unit installation and remote control as an option.

Maintenance Free Transmission System

The air end is connected directly to an electric motor (with or without step-up gear). Direct transmission is a significant attribute of our big-capacity screw compressor packages as it makes the operation of the air end possible with the highest effectiveness.


Model 		Power Pressure Flow Rate
HP kW Bar CFM M3/ min
SIGMA Σ 30+ 30 22 6 – 8 – 10 144 – 128 – 114 4.07 – 3.63 – 3.23
ZIGMA Z 40+ 40 30 6 – 8 – 10 205 – 177 – 155 5.8 – 5.04 – 4.40
MEGA M 50 37 6 – 8 – 10 254 – 230 – 191 7.2 – 6.5 – 5.43
GIGA G 60 45 6 – 8 – 10 314 – 276 – 240 8.88 – 7.83 – 6.80
TERA T 75 55 6 – 8 – 10 392 – 336 – 293 11. 9.53 – 8.29
PETA P 100 75 6 – 8 – 10 490 – 454 – 399 13.89 – 12.88 – 11.32

Model 		Power Pressure Flow Rate
HP kW Bar CFM M3/ min
NANO N 7.5 7.5 5.5 8 – 10 – 12 31- 28 – 26 0.88 – 0.80 – 0.74
ALFA α 10+ 10 7.5 8 – 10 – 12 45 – 42 – 38 1.30 – 1.20 – 1.08
BETA β 15+ 15 11.0 8 – 10 – 12 62 – 59 – 56 1.80 – 1.70 – 1.58
GAMMA γ 20+ 20 15.0 8 – 10 – 12 88 – 85 – 82 2.25 – 2.40 – 2.32
DELTA Δ 25+ 25 18.5 8 – 10 – 12 101 – 98 – 94 2.86 – 2.78 – 2.66
SIGMA Σ 30+ 30 22.0 8 – 10 – 12 125 – 121 – 115 3.52 – 3.44 – 3.28

Applications

Single-stage rotary screw air compressors, Two Stage Screw Compressor used in stationary and mobile applications with air discharge temperature up to 120°C.

Benefits

The advantages of using Saimona screw air compressors are

  • Remarkable resistance to deposit formation guarantees improved air compressor.
  • Efficiency and therefore prolonged running periods and decreased maintenance costs.
  • Outstanding demulsibility makes sure that the oil separator element functions smoothly.
  • Excellent comprehensive protection against corrosion, rusting, and wear.
  • Supreme oxidation and thermal stability hence longer oil drain interval.

We Supply

We Supply premium quality air compressor lubricants at prices that will allow your customers to save up money over OEM lubricants. OEM doesn’t necessitate buying lubricants from them to retain your warranty.

State-of-the-art Compressor Airend

Maximum energy efficiency & extraordinary reliability is accomplished from patented design third generation non-symmetric robust rotors, first-class bearings & oil seal that facilitates the compressor airend to operate with great dynamic balance, low vibration, low rotation speed and low noise level.

Energy Saving Electric Motor

Our remarkable modified electric motor can achieve high efficiency of 95.2% that saves an unparallel level of energy. Top-class, high-speed bearings from ‘SKF’ are fitted for continuous operation without any hitch.

High Efficient Air & Oil coolers

The enlarged high-efficiency oil & air combination air-cooled after cooler is explicitly crafted for South East Asia climate to insure that all the components work properly even under high ambient temperatures & humid summer season. All design data are referenced at 46°C ambient temperature.

Modern Concept Suction Control System

Modern concept suction control valve with automatic closure to prevent any oil to escape. The control unit can automatically adjust from 60-100% in accordance with the requirement of the system air to adequately minimize operating cost.

Modern Concept Suction Control System

High-Quality Genuine Spare Parts

All high-quality and durable spare parts are designed, manufactured and tested in Europe so that the most stringent and exact international standards can be completely met.

High Performance

The products from Saimona Compressor LTD are equipped with new high-capacity and developed airend.

Low Noise Design

The feature of low noise is successfully achieved by the low-noise rotor profile, adoption of a vibration-proof driving system and low-noise structure of suction and exhaust.

Energy Saving

  • Stranded Compressor
  • Purchasing Cost
  • Maintenance Cost
  • Energy Cost

VSD Compressor

  • Purchasing Cost
  • Maintenance Cost
  • Energy Cost
  • Energy Saving
